Door and window hinge installation diagram - introduction of spring hinge installation method step b

Introduction to the installation method of spring hinges, detailed answers to the steps and procedures

Spring hinges, as the name implies, are special hinges installed on some spring doors or other cabinet doors, so how should spring hinges be selected? What are the processes and precautions that should be learned and understood during the installation process? Yes Consumers who are similarly confused can consider the following comprehensively. What we recommend for you is the detailed introduction on the installation method of spring hinges and detailed analysis of text and pictures. We can use this small spare parts to achieve more Steady details in terms of operational effects.

the

1. Brief introduction of spring hinge

The spring hinge is a hinge that can automatically close the door after it is opened. It is equipped with a spring and an adjusting screw, which can adjust the height and thickness of the plate up and down, left and right. The single spring hinge can only be opened in one direction, and the double spring hinge can be opened in and out. Two-way opening, mainly used on the gates of public buildings. Double spring hinges can be opened in both directions, with compact structure, built-in coil spring, equipped with a hexagonal wrench to freely adjust the spring pressure, advanced design, no noise in operation, and durable. Equipped with stainless steel hinge head, strong elastic iron spring and placed with high-quality resistance oil, the operation is smooth, stable, and noiseless. The surface treatment is meticulous, uniform, and sharp-edged; the thickness, size, and material of the hinge are accurate.

the

2. Spring hinge installation method

Before installation, check whether the hinge matches the door and window frame and leaf, check whether the hinge groove matches the height, width and thickness of the hinge, check whether the hinge and the screws and fasteners connected to it are matched. The connection of the spring hinge The method should match the material of the frame and leaf. For example, the hinge used for the steel frame wooden door, the side connected to the steel frame is welded, and the side connected to the wooden door leaf is fixed with wood screws. When the leaf boards are asymmetrical, it should be identified which leaf board should be connected to the fan, which leaf board should be connected to the door and window frame, the side connected to the three sections of the shaft should be fixed to the frame, and the side connected to the two shaft sections should be fixed One side should be fixed with the door and window. When installing, ensure that the shafts of the hinges on the same leaf are on the same vertical line to prevent the door and window leaf from springing up. Before installing the spring hinge, it is necessary to determine whether the door type is a flat door or a rebated door. Door frame material, shape and installation direction.

1. Insert a 4mm hexagonal key into the hole at one end, press firmly to the end, and open the hinge at the same time.

2. Install the hinges into the hollowed-out grooves on the door leaf and door frame with screws.

3. Close the door leaf, make the spring hinges in the closed state, insert the hexagonal key again, do not need to press down, turn clockwise to rotate, and you can hear the sound of the gears meshing four times, do not exceed four times !If it exceeds four times, because the spring has been twisted to the limit, the spring will be damaged and lose its elasticity when the door leaf is opened.

4. After the hinge is tightened, the opening angle cannot exceed 180 degrees.

5. If you want to loosen the hinge, just do the same operation as step 1.

The spring hinge recommended above is more flexible because it is designed with a spring device. It has a wider scope of application than ordinary hinges, and common spring doors generally use this special spring hinge. Page, so how to choose a spring hinge? Where should we start to understand and consider the purchase operation? Consumers who have similar confusion or want to learn similar suggestions and knowledge can learn from the above and believe that they can achieve satisfaction. actual use effect.

Detailed explanation of the installation steps of wooden door hinges Installation precautions of wooden door hinges

Regarding the installation of wooden door hinges, many people must not be very clear, because these things are usually installed by decoration masters for us, but if the door and window hinges at home are broken, it is just such a small problem. If you dont want to bother, if you make a special trip to ask the master to repair it, you can actually do it yourself. So, what are the specific installation steps for the wooden door hinge? What precautions should be taken when installing the wooden door hinge? Lets take a look below Get up and see.

Detailed explanation of the installation steps of the wooden door hinge

1. For the connection between the hinge and the door leaf, measure 200mm and draw the positioning line. Align the short side of the hinge with the drawn line, align the long side of the hinge with the back of the door leaf, and then use the hinge as a template to draw Use a flat chisel to remove the outline of the hinge groove. The hinge groove should be deep on the inside and shallow on the outside. , put it into the hinge, temporarily fix it with 2 screws, and use the same method to temporarily fix the hinge at the lower part of the door leaf.

2. The connection between the hinge and the door frame, draw the positioning line of the upper hinge of the door frame: use a steel tape to measure 200mm from the upper part of the door frame and draw the positioning line, align the hinge with the drawn positioning line and the edge of the door frame, And use the hinge as a template to draw the outline of the hinge groove. The positioning line of the lower hinge of the door frame still starts from the upper part of the door frame, and the height of the door leaf is measured downward minus 200mm.

3. Finally, use a flat chisel to cut out the hinge groove. After the upper and lower hinge grooves are cut out, put the door leaf into the frame, and temporarily fix the upper and lower hinges on the door frame with 2 screws. Then check whether the gap of the wooden door meets the requirements. Requirements, whether the frame and the leaf are flush, whether the door leaf is opened and closed normally, it is better for the door leaf to stop wherever it opens, and it cannot be self-closing or self-closing. After the inspection is qualified, tighten the remaining screws superior.

Precautions for installation of wooden door hinges

The hinge is an important hardware accessory on the door. It is a linking part that links the door leaf and the door frame. Its quality directly affects the performance and quality of the wooden door. A three-prong hinge with the characteristics of flexibility and noise reduction is suitable.

A good hinge is in the form of bearings. Generally, there are 4 bearings in one, and there is damping oil in it. When a good quality hinge is unfolded horizontally, it should slide down slowly like this, and there is no need for effort when closing the door. It will not hit the door on the door frame at once; the door is firmly connected and will not suddenly fall down to cause a safety hazard.

When installing wooden door hinges, the hinges should be vertical and flat, and the flat hinges should be slotted correspondingly to the door leaf and door casing. The hinge should be flexible and free to open. The three-prong hinge should be installed according to the mold, and the pin should be inserted in place. The hinge fixing screws should be fully installed, straight, and hidden in the hinge plane. In short, different types of hinges must pay attention to all Details to ensure that the solid wood door can be opened smoothly.

The connection method of the hinge should match the material of the frame and leaf, such as the hinge used for the steel frame wooden door, the side connected with the steel frame is welded, and the side connected with the wooden door leaf is fixed with wood screws. In addition, in When the two leaf plates of the hinge are asymmetrical, it should be identified which leaf plate should be connected to the fan, which leaf plate should be connected to the door and window frame, and the side connected to the three sections of the shaft should be fixed The side where the two segments are connected should be fixed to the frame.

After reading the relevant introduction of the above articles, everyone must have understood the detailed explanation of the installation steps of wooden door hinges and the installation precautions of wooden door hinges. In fact, the installation steps of wooden door hinges are not too difficult. Everyone has needs. At that time, this article can actually serve as a basic reference for everyone, and I hope it can be helpful to everyone. If you want to know more about thermal insulation broken bridge doors and windows, please continue to browse our website.

How to install the hinges of interior doors: 1. Check whether the purchased door hinges are complete. If you buy accessories online, whether the screws are in order, and the quality of the door hinges. Check whether the door hinges and door leaves to be installed are complete. Matching. 2. Determine the direction to open the door, whether to open to the left or to the right. 3. Follow the steps to confirm the installation position of the hinge with a pencil, such as A punching holes. Then connect a door panel to the hinge on the door frame as in C Installed. 4. Use the hexagonal key to tighten the door panel (door frame) hinge screws. 5. Put the door panel on the door frame hinge and complete. In short, the hinge must be measured in advance before installing the door hinge. The specific location, or the rear door will be crooked if it is not installed.

The classification of hinges can be classified from many aspects such as shape and use, and the names of different classifications of hinges are also different. General hinges can be divided into ordinary hinges, pipe hinges, door hinges, bearing hinges, and bevel detachment Hinges and cold storage door hinges, etc.

Villa Master provides you with local housing policies, housing drawings, and villa design drawings;

Villa appearance rendering service, you can choose from thousands of popular drawings: https://www.bieshu.com? How to install bdfc single door double hinge

Install the single-door double-opening hinge, and compare the position of the hinge on the door; the specific operation steps are as follows:

1. Prepare the hinge.

2. Align the hinge on the door.

3. Put the door down and fix the middle of the hinge on the door.

4. Stand up the door and align the outer ring of the hinge on the door frame.

5. Fix the outer ring of the hinge on the door frame.

6. The installation is complete.

The door hinge is a device that connects two solids. The door hinge is also an essential and very important part in our home decoration life. In fact, the existence of the door hinge is conducive to the safety of our home decoration life and ensures the safety between the two. Therefore, it is very important to understand the principle and installation method of the door hinge, so how should the door hinge be installed? What is the installation standard? Let the editor explain how to install it The door hinge, I hope it will be helpful for everyone to increase the knowledge of the door hinge!

Ordinary door hinge installation position

Ordinary hinges are the most commonly used ones, and they are widely used in the home. Today's door hinges are becoming more and more refined, and the technology is becoming more and more sophisticated. Presumably for the previous hinges , Today's ordinary hinges have different materials and different effects. So what is the installation position of ordinary door hinges? Installed in different positions, their stress points will also be affected. Ordinary ordinary door hinges The installation position is about a quarter of the door, so as to ensure uniform force. It will not affect the opening and closing of the door and daily use.

Installation location of pipe door hinge

The pipe hinge has a spring device, which is mainly used for the connection on the door panel of the furniture. The thickness of this hinge is required to be 16 to 20mm. There are two kinds of materials, zinc alloy and galvanized iron, and there are screws to adjust The installation position of the door hinge. The thickness and height can be adjusted left and right, up and down. So what is the installation position of the door hinge of this type of pipe? It is best to install a hinge in the upper and lower directions of the door, all on the three sides of the door One part. This kind of door hinge installation position is also the most installation method nowadays, and the force point is relatively uniform.

Large room door hinge installation location

The installation position of the door hinge can be regarded as the hinge installation of the entrance and exit of the home. If it is the installation position of the door hinge, then in the selection of the hinge, the hinge with good quality and excellent performance should be selected. From the current market Look, this kind of hinges suitable for gates is generally made of copper bearing hinges. Moreover, the style is relatively generous, the price is also very moderate, and it is also equipped with screw devices. So what is the installation position of this kind of gate hinges? What? A hinge can be installed at the upper, middle and lower points of the door, and each hinge occupies a third of the position.

Other door hinge installation positions

In addition to the above door hinge installation positions, there are many other ways to install different door hinges, and there are many other door hinges, such as flap door hinges, countertop hinges, glass hinges, etc. The glass hinge is suitable for installation on the glass door without frame, and the thickness of the glass door should not be greater than 5mm or 6mm. If these other hinges cannot find the right door hinge installation position, you may wish to use the above several door hinges The installation position method is also possible for these hinges, the most important thing is to consider whether the stress points of the door are even.

Door hinge installation position standard

Different doors also have different heights and thicknesses, so the installation position of the door hinge must also change accordingly. Therefore, there is no standard for the installation position of the door hinge, and it is carried out according to most installation methods in the market. For example, the door has 2 meters high, when installing the hinge, the best door hinge installation position is 18 cm above the door edge and 20 cm below the ground. If it is an ordinary door, refer to the installation position of other door hinges in the room. This is to achieve perfect unity and beautiful decorative effect, so that each door will also make the force points evenly due to the installation of hinges.

Seeing this, I believe everyone has a certain understanding of the installation of the door hinge. In fact, the installation of the door hinge is not complicated. There are different installation methods for different door hinges, as long as you master the tricks , Installing the door hinge will become very simple. Here, the editor hopes that everyone can master this kind of home improvement common sense and the installation of small parts, and can operate it. In this way, in our daily life If you encounter problems in this area in life, you will not be at a loss!

How to install the standard hinge on the wooden door

Generally, only two hinges are needed for wooden doors. When opening the hinge slot, slots must be made on the door leaf and the door cover. And the position of the hinge should be nailed on the wall to ensure the firmness of the screws.

As long as your door is installed horizontally and vertically, two hinges are usually enough. I have been doing it for a year, and the original wooden door uses two hinges so far without any problems.

If you must have three hinges, the hinge in the middle should be closer to the hinge on the top. The distance between the hinges at both ends and the corner should be about 250300mm.

Cabinet door hinge installation method

There is another name for cabinet door hinges called hinges. This is mainly used to connect our cabinets and our cabinet doors. It is also a common hardware accessory. Cabinet door hinges are used in our cabinets. Time is very important. We open and close many times a day, and the pressure on the door hinge is very great. Many people don't know how to install it after buying it. Today I will introduce you to the installation of the cabinet door hinge. method.

the

Introduction to the installation method of the cabinet door hinge

Installation method and method

Full cover: The door completely covers the side panel of the cabinet body, and there is a certain gap between the two, so that the door can be opened safely.

Half cover: Two doors share a cabinet side panel, there is a required minimum gap between them, the coverage distance of each door is reduced, and a hinge with hinge arm bending is required. The middle bend is 9.5MM.

Inside: The door is located inside the cabinet, beside the side panel of the cabinet body, it also needs a gap to facilitate the safe opening of the door. A hinge with a very curved hinge arm is required. The big bend is 16MM.

First of all, we need to install the hinge cup. We can use screws to fix it, but the screws we choose need to use flat countersunk head chipboard self-tapping screws. We can use this kind of screw to fix the hinge cup. Of course, we can also use Tool-free, our hinge cup has an eccentric expansion plug, so we use our hands to press it into the pre-opened hole of the entry panel, and then pull the decorative cover to install the hinge cup, the same unloading The same is true of time.

After the hinge cup is installed, we still need to install the hinge seat. When we install the hinge seat, we can also use screws. We still choose particleboard screws, or we can use European-style special screws, or some pre-installed special expansion plugs. Then the hinge seat can be fixed and installed. There is another way for us to install the hinge seat is the press-fitting type. We use a special machine for the hinge seat expansion plug and then press it in directly, which is very convenient.

Finally, we need to install the cabinet door hinges. If we dont have tools for installation, it is recommended that you use this tool-free installation method for cabinet door hinges. This method is very suitable for quick-installed cabinet door hinges, which can be used The way of locking, so that it can be done without any tools. We first need to connect the hinge base and the hinge arm at our lower left position, and then we buckle down the tail of the hinge arm, and then Gently press the hinge arm to complete the installation. If we want to open it, we only need to press lightly on the left empty space to open the hinge arm.

We use a lot of cabinet door hinges, so after a long time of use, it is inevitable that there will be rust, and if the cabinet door is not closed tightly, then we'd better replace it with a new one, so that we can use it with more confidence.

Cabinet door hinge installation method:

1. Minimum door margin:

First of all, we need to determine the minimum door margin between the cabinet doors to be installed, otherwise the two doors are always "fighting", which is not beautiful and practical. The minimum door margin depends on the type of hinge, hinge cup margin and cabinet Select the value based on the thickness of the door. For example: the thickness of the door panel is 19mm, and the edge distance of the hinge cup is 4mm, so the minimum door edge distance is 2mm.

2. Selection of the number of hinges

The number of cabinet links selected should be determined according to the actual installation experiment. The number of hinges used for the door panel depends on the width and height of the door panel, the weight of the door panel, and the material of the door panel. For example: a door panel with a height of 1500mm and a weight between 9-12kg, 3 hinges should be used.

3. Hinges adapted to the shape of the cabinet:

The cabinet with two built-in rotatable pull baskets needs to fix the door panel and the door frame at the same time. The most important thing is that the built-in pull basket determines its opening angle to be very large, so the curvature of the hinge must be large enough to ensure that it can Freely open the cabinet door to a suitable angle, and conveniently take and place any items.

4. Selection of hinge installation method:

The door is divided according to the position of the door side and the side of the side panel, and there are three installation methods: full cover door, half cover door and embedded door. The full cover door basically covers the side panel; the half cover door covers the side panel. The half of the board is especially suitable for cabinets with partitions in the middle that need to install more than three doors; the embedded doors are installed in the side boards.

The above is the installation method of the cabinet door hinge introduced to you. Are you clear? In fact, the installation of the cabinet door hinge is very simple, we can install it without tools, but if you dont know what to do after reading the above How to install it, I suggest that you better find someone to install it, so that you can be more assured, and it will not cause any problems in your life due to poor installation.
