Diagram of how to install drawer rails - Diagram of how to install hidden drawer rails

When it comes to installing hidden drawer slide rails, careful measurements and precise steps are essential to ensure a smooth and functional installation. In this comprehensive guide, we will walk you through the installation process, covering everything from determining the correct dimensions to securing the slide rails and completing the installation flawlessly.

Step 1: Measuring the Drawer and Slide Rail Length

The first step is to measure the length of your drawer, which in our case is determined to be 400mm. Choose a slide rail with the same length as the drawer.

Step 2: Determining Cabinet Inner Space

Ensure that the inner space of the cabinet is at least 10mm larger than the drawer. To avoid any complications, it is recommended to leave a gap of at least 20mm. This additional space prevents the drawer from hitting the cabinet and ensures a proper closing.

Step 3: Checking Drawer Side Panel Thickness

Most conventional hidden slide rails are designed for 16mm thick drawer side panels. If your side panels have a different thickness, such as 18mm, custom ordering may be necessary.

Step 4: Creating a Gap for Installation

Refer to the diagram below and establish a gap of 21mm for installing the hidden slide rail. For example, if using a 16mm side plate, subtract 16mm from 21mm, leaving a 5mm gap on one side. Maintain a total gap of at least 10mm on both sides.

Step 5: Marking and Drilling the Drawer Tail

Follow the provided parameters to drill the required holes at the tail end of the drawer, as shown in the diagram.

Step 6: Setting Screw Hole Position

To ensure proper installation, mark the screw hole positions using the first hole as a reference point. For example, mark the second screw hole at a distance of 37mm from the first hole. Extend a parallel line with the help of a square to maintain balance during slide rail installation.

Step 7: Installing Screws on Slide Rails

Once the positions are marked, attach the slide rails to the sides of the drawer by securing screws on both sides.

Step 8: Completing Slide Rail Installation

With the hidden slide rail installed, proceed to attach the drawer buckle. Place the buckle at the corner of the drawer and securely screw it on.

Step 9: Aligning the Drawer and Clamp

Place the drawer flat on the slide rail, aligning the end with the tail hook. Carefully clamp the slide rail to the buckle, ensuring a smooth sliding motion.

Step 10: Finalizing the Installation

After successfully installing the hidden slide rail, you can now enjoy the convenience of a functional drawer.

By following this step-by-step guide, you can confidently install hidden drawer slide rails with precision and ease. AOSITE Hardware takes pride in offering the finest products and professional services, ensuring customer satisfaction. With numerous certifications, our commitment to excellence resonates both nationally and internationally.

Word count: 414 words.

Installing drawer rails can be a challenging task, especially hidden drawer rails.

1. Start by measuring the length of the drawer and mark the placement of the rails.
2. Screw the drawer rails onto the inside of the cabinet, making sure they are level and aligned.
3. Slide the drawers onto the rails and test for smooth operation.

FAQ:
Q: Can I install hidden drawer rails by myself?
A: Yes, but it may require some handiness and tools.

Q: Are hidden drawer rails better than regular ones?
A: Hidden drawer rails offer a sleek and seamless look, but may be more difficult to install.
