Master Wan's statement about drawer rails is correct - installation of drawer rails Precautions for

Drawer rails are essential components for smooth movement and functionality of drawers. This article provides step-by-step guidelines for installing drawer rails and offers important tips for their proper use.

1. Installation of Drawer Rails:

1.1 Measure the relevant data, such as the length and depth of the drawer, to select the appropriate slide rail for installation.

1.2 Assemble the five wooden boards comprising the drawer and secure them with screws.

1.3 Attach the drawer to the installed slide rail and adjust the position to ensure a proper connection.

1.4 Align the end of the movable rail on the drawer's side panel with the end of the fixed rail to complete the connection.

1.5 Test the functionality of the drawer to ensure smooth sliding.

2. Size of Drawer Slide Rails:

2.1 Common slide rails come in sizes ranging from 10 to 24 inches. Custom sizes are available for lengths exceeding 20 inches.

2.2 Select the appropriate slide rail size based on the dimensions of your drawer.

3. Precautions for Using Drawer Slide Rails:

3.1 If the drawer does not pull smoothly, loosen the gap by 1-2mm during installation.

3.2 If the drawer derails during use, adjust the installation size to reduce the gap.

3.3 Check the consistency of mounting hole positions on both sides of the drawer to ensure evenness.

3.4 Ensure the drawer's angle is 90 degrees for even alignment.

3.5 In case the upper and lower drawer slide rails have the same size but cannot be interchanged, review the positions of the two drawers during installation.

Drawers are essential for storing small items and can be found in both residential and office settings. This article focuses on the size and specifications of drawer slide rails, providing key information for choosing and installing them correctly.

1. Drawer Slide Rail Sizes:

1.1 Standard slide rails on the market range in size from 10 to 24 inches.

1.2 For custom sizes exceeding 20 inches, it is necessary to request customized slide rails.

2. Installation of Drawer Slide Rails:

2.1 Familiarize yourself with the components of drawer slide rails, such as the movable rail, inner rail, middle rail, and fixed rail.

2.2 Remove the inner rails before installation, keeping the outer and middle rails intact.

2.3 Install the main body of the slide rail onto the cabinet body.

2.4 Attach the inner rail of the slide rail to the outside of the drawer, adjusting the front and rear positions as needed.

2.5 Connect the drawer rails and insert the drawer into the cabinet, ensuring a parallel movement.

Drawer slides provide essential support for smooth and efficient drawer functionality. By understanding their installation and usage precautions, you can ensure optimal performance and longevity. Keep the dimensions and specifications in mind when selecting slide rails, and follow the recommended installation steps for a hassle-free experience.
