Hydraulic Damping Hinge For Furniture Cupboard

1. Nickel plating surface treatment 2. Fixed appearance design 3. The built-in damping

    oops...!

    no product data.

    Go to homepage

    Hydraulic Damping Hinge For Furniture Cupboard 7

    Hydraulic Damping Hinge For Furniture Cupboard 8


    Products Real Shot

    1. Nickel plating surface treatment

    2. Fixed appearance design

    3. The built-in damping


    Hydraulic Damping Hinge For Furniture Cupboard 9

    Hydraulic Damping Hinge For Furniture Cupboard 10


    Show Details

    a. High-quality cold-rolled steel

    Made by Shanghai Baosteel, nickel-plated double sealing layer, long corrosion resistance and long service life


    b. 5 pieces of thickness arm

    Enhanced loading capacity, strong and durable


    c. Hydraulic cylinder

    Damping buffer, light opening and closing, good quiet effect


    d. 50,000 durability tests

    The product is firm and wear-resistant, long-term use as new


    e. 48 hours neural salt spray test

    Super anti-rust ability


    Hydraulic Damping Hinge For Furniture Cupboard 11

    Hydraulic Damping Hinge For Furniture Cupboard 12

    Hydraulic Damping Hinge For Furniture Cupboard 13


    Product Parameter

    Product name: One-way hydraulic damping hinge

    Opening angle: 100°

    Diameter of hinge cup: 35mm

    Cover adjustment: 0-6mm

    Depth adjustment: -3mm~+3mm

    Base up and down adjustment: -2mm~+2mm

    Door panel drilling size: 3-7mm

    Applicable door thickness: 16-20mm

    Hole distance: 48mm

    Cup depth: 11.3mm


    Atmospheric yet calm, the classic reproduction of light luxury and practical aesthetics. Function, space, stability, durability, beauty.


    Hydraulic Damping Hinge For Furniture Cupboard 14

    Hydraulic Damping Hinge For Furniture Cupboard 15

    Hydraulic Damping Hinge For Furniture Cupboard 16

    Advantages

    Advanced Equipment, Superb Craftsmanship, High-Quality, ConsideRate After-Sales Service, Wordwide Recognition & Trust.


    Quality-Reliable Promise for you

    Multiple Load-Bearing Tests, 50,000 Times Trial Tests, And High-Stregth Anti-Corrosion Tests.


    Standard-make good to be better

    ISO9001 Quality Management, Swiss SGS Quality Testing and CE CERTIFICATION.


    Service-Promising Value You Can Get

    24-Hour Response Mechanism

    1-TO-1 All-Round Professional Service


    INNOVATION-EMBRACE CHANGES

    Persist in the innovation leding, The development

    Hydraulic Damping Hinge For Furniture Cupboard 17

    Hydraulic Damping Hinge For Furniture Cupboard 18

    Hydraulic Damping Hinge For Furniture Cupboard 19

    Hydraulic Damping Hinge For Furniture Cupboard 20

    Hydraulic Damping Hinge For Furniture Cupboard 21

    Hydraulic Damping Hinge For Furniture Cupboard 22

    Hydraulic Damping Hinge For Furniture Cupboard 23


    PRODUCT OVERVIEW
    Hydraulic Damping Hinge For Furniture Cupboard 24
    Hydraulic hinge is a type of furniture hinge that features a hydraulic buffer. It is a mechanism that slows down the closing action of the hinge to prevent slamming, and ensure a smooth and silent close. This feature of hydraulic hinges is particularly important in modern home designs where noiseless living environments are a key consideration. The hydraulic buffer helps to protect the furniture and maintain its longevity as it prevents wear and tear from constant banging. It is a popular hinge for cabinets, doors, and kitchen furniture due to its easy installation, durability, and the added convenience of its buffer feature.
    SPECIFICATIONS

    Product name

    One way hydraulic damping hinge

    Diameter of hinge cup

    35mm

    Cover adjustment

    0-6mm

    Depth adjustment

    ±3mm

    Base up and down adjustment

    ±2mm

    Door panel drilling size

    3-7mm

    Opening angel

    100°

    Applicable door thickness

    16-20mm

    Hole distance

    48mm

    Cup depth

    11.3mm

    PRODUCT FEATURES
    图片9 (3)
    High-quality cold-rolled steel
    Made by Shanghai Baosteel, nickel-plated double sealing layer, long corrosion resistance and long service life
    图片10 (3)
    5 pieces of thickness arm
    Enhanced loading capacity, strong and durable
    图片11 (3)
    Hydraulic cylinder
    Damping buffer, light opening and closing, good quiet effect
    图片12 (3)
    50,000 durability tests
    The product is firm and wear-resistant, long-term use as new

    CERTIFICATE
    1 (48)
    1 (48)
    2 (46)
    2 (46)
    3 (42)
    3 (42)
    4 (28)
    4 (28)
    5 (29)
    5 (29)
    2 (17)
    2 (17)
    3 (13)
    3 (13)
    INSTALLATION
    图片13 (3)
    PRODUCT PACKAGING
    1 (18)
    1 (18)
    2 (16)
    2 (16)

    FAQ
    1
    What is your factory product range?
    Hinges, Gas spring, Tatami system, Ball bearing slide, Handles
    2
    Do you provide samples? Is it free or extra?
    Yes, we provide free samples
    3
    How long does the normal delivery time take?
    About 45 days
    4
    What kind of payments does support?
    T/T
    5
    Do you offer ODM services?
    Yes, ODM is welcome
    6
    How long is the shelf life of your products?
    More than 3 years
    7
    Where is your factory, can we visit it?
    Jinsheng Industry Park, Jini Town, Gaoyao District, Zhaoqing, Guangdong, China
